"Raschig Super-Ring®" which sets new performance standards in the use of mass transfer columns. The Raschig Super-Ring® optimized fluid-dynamic design produces an effective mass transfer between the phases flowing in the column. It achieves large interfaces and an even distribution of the liquids over the column cross-section. High loading capacities permit large column throughputs, and low pressure drops yield low operating costs.
Features
- Liquid film flow with entangled packing, similar to our latest model SPIRAX, resulting in large material transfer (Same effect is confirmed with our product, TELLERETTE.)
- Flooding at joints prevented with “Semi Structured Packing”
- Support rings do not have to be completely removed when remodeling shelf block towers
- However, when remodeling to standard packings, support rings need to be completely removed up to the outer-circumference edge.
- Reduced number of redistributors with homogeneous liquid distribution
- Cost savings with high-speed machines
- RSR is available in SUS as well as materials that are thick or thin such as titan, nickel, and tantalum
- HETP, pressure loss and intensity are far beyond the most efficient random packings
- Verified high performance of RSR by tests in the world-class distillation research institute, FRI (Fractionation Research, Inc.)
Major Applications
- Absorption, diffusion and distillation towers
Specification of Raschig Super-Ring (RSR)
Raschig Super-Ring
(model number) |
Weight (kg/m3) |
Bulk Quantity
(number/m3) |
Surface Area
(m2/m3) |
Void (%) |
Size (Diameter) |
| [mm] |
[inch] |
| RSRNo.0.3 |
340 |
180,000 |
315 |
96 |
15 |
0.3 |
| RSRNo.0.5 |
275 |
145,000 |
250 |
97 |
20 |
0.5 |
| RSRNo.0.7 |
250 |
45,500 |
180 |
98 |
25 |
0.7 |
| RSRNo.1 |
220 |
32,000 |
150 |
98 |
30 |
1 |
| RSRNo.1.5 |
190 |
13,100 |
120 |
98 |
38 |
1.5 |
| RSRNo.2 |
165 |
9,500 |
100 |
98 |
50 |
2 |
| RSRNo.3 |
150 |
4,300 |
80 |
98 |
70 |
3 |
|
|
