PTFE lining flangePTFE lining flange
PTFE lining flange
ptfe, polytetrafluoroethylene, ptfe chemical hole panel, ptfe electricity insulated hang, ptfe chemical liquid distributing ware, ptfe collecting ware, ptfe pp lining three way pipe tee with flange, ptfe pp lining conduit pipeline with flange, ptfe chemical abnormity accessory lining, ptfe glass fibre complex, machine sealing ptfe accessory, static sealing gasket spacer shim, ptfe graphite asbestos filling, ptfe sealing gasket, ptfe mould pressing board sheet, ptfe turning board sheet, ptfe accessory as machinery processing blank, non filling ptfe sealing packing, non assistant reagent ptfe sealing packing, ptfe air condition valve core, ptfe oriented belt, ptfe piston ring, ptfe oriented ring, ptfe sealing ring, special rubber sealing parts, ptfe high voltage electricity inducting bar.
Housing Material:

Carbon Steel conforms to ASTM A516 GR 70 or SAE 1010-1030.

1" - 8" sizes are rated for full vacuum to 450

10" and 12" are not vacuum rated.

Class 150
Major
Size
(in.)		 Minor
Size
(in.)		 Part Numbers Thickness OD H-Bolt Holes E-Bolt Holes Flare Dia.
(No.)
Size		 Bolt
Circle
Dia.		 (No.)
Size		 Bolt
Circle
Dia.		 Depth
B A G D F C J
1 1/2  110905FS 1 1/2 4 1/4 (4)
1/2-13		 3 1/8 (4)
1/2-13		 2 3/8 11/16 2 1 7/8
3/4  110975FS 2 3/4
1 1/2 1  115910FS 1 1/2 5 (4)
1/2-13		 3 7/8 (4)
1/2-13		 3 1/8 9/16 2 7/8 2
2 1  120910FS 1 1/2 6 (4)
5/8-11		 4 3/4 (4)
1/2-13		 3 1/8 9/16 3 5/8 2
1 1/2  120915FS 3 7/8 2 7/8
3 1  130910FS 1 1/2 7 1/2 (4)
5/8-11		 6 (4)
1/2-13		 3 1/8 9/16 5 2
1 1/2  130915FS 3 7/8 5/8 2 7/8
2  130920FS (4)
5/8-11		 4 3/4 3/4 3 5/8
4 1 140910FS  2 9 (8)
3/4		 7 1/2 (4)
1/2-13		 3 1/8 9/16 6 3/16 2
1 1/2  140915FS 3 7/8 5/8 2 7/8
2  140920FS 1 1/2 (4)
5/8-11		 4 3/4 3/4 3 5/8
3  140930FS (8)
5/8-11		 6 5
6 1 160910FS  2 11 (8)
7/8		 9 1/2 (4)
1/2-13		 3 1/8 9/16 8 1/2 2
1 1/2  160915FS 3 7/8 5/8 2 7/8
2  160920FS (4)
5/8-11		 4 3/4 3/4 3 5/8
3  160930FS 6 5
4  160940FS 1 1/2 (8)
3/4-10		 (8)
5/8-11		 7 1/2 6 3/16
8 3  180930FS 2 13 1/2 (8)
7/8		 11 3/4 (4)
5/8-11		 6 3/4 10 5/8 5
4  180940FS 7 1/2 6 3/16
6 180960FS 1 1/2 (8)
3/4-10		 (8)
3/4-10		 9 1/2 13/16 8 1/2
10 3  185930FS 2 16 (12)
1		 14 1/4 (4)
3/4-10		 6 5/8 12 3/4 5
4  185940FS (8)
3/4-10		 7 1/2 3/4 6 1/2
6  185960FS 9 1/2 13/16 8 1/2
8  185980FS (12)
7/8-9		 11 3/4 10 5/8
12 6  190960FS 2 19 (12)
1		 17 (8)
3/4-10		 9 1/2 13/16 15 8 1/2
8  190980FS 11 3/4 10 5/8
10  190985FS (12)
7/8-9		 (12)
7/8-9		 14 1/4 1 1/4 12 3/4

Class 300
Major
Size
(in.)		 Minor
Size
(in.)		 Part Numbers Thick
ness		 OD H-Bolt Holes E-Bolt Holes Flare Dia.
(No.)
Size		 Bolt
Circle
Dia.		 (No.)
Size		 Bolt
Circle
Dia.		 Depth
B A G D F C J
1 1/2 110905-3 15/16 4 7/8 (4)
5/8-11		 3 1/2 (4)
1/2-13		 2 5/8 9/16 2 1 3/4
3/4 110975-3 (4)
5/8-11		 3 1/4 1 11/16
1 1/2 1/2 115905-3 1/16 6 1/8 (4)
3/4-10		 4 1/2 (4)
1/2-13		 2 5/8 9/16 2 7/8 1 3/8
1 115910-3 1 1/2 (4)
5/8-11		 3 1/2 5/8 2
2 1 120910-3 1 1/2 6 1/2 (8)
5/8-11		 5 (4)
5/8-11		 3 1/2 5/8 3 5/8 2
1 1/2 120915-3 (4)
3/4-10		 4 2 7/8
3 1 130910-3 1 1/2 8 1/4 (8)
3/4-10		 6 5/8 (4)
5/8-11		 3 1/2 5/8 5 2
1 1/2 130915-3 (4)
3/4-10		 4 1/2 2 7/8
2 130920-3 (8)
5/8-11		 5 3/4 3 5/8
2 1/2 130925-3 1 3/8 (8)
3/4-10		 5 7/8 4 1/8
4 1 140910-3 2 10 (8)
7/8		 7 7/8 (4)
5/8-11		 3 1/2 5/8 6 3/16 2
1 1/2 140915-3 (4)
3/4-10		 4 1/2 2 7/8
2 140920-3 1 1/2 (8)
3/4-10		 (8)
5/8-11		 5 3/4 3 5/8
3 140930-3 (8)
3/4-10		 6 5/8 5
6 1 160910-3 2 12 1/2 (12)
7/8		 10 5/8 (4)
5/8-11		 3 1/2 5/8 8 1/2 2
1 1/2 160915-3 (4)
3/4-10		 4 1/2 1 2 7/8
2 160920-3 (8)
5/8-11		 5 3/4 3 5/8
3 160930-3 (8)
3/4-10		 6 5/8 5
4 160940-3 1 1/2 (12)
3/4-10		 7 7/8 6 3/16
8 1 180910-3 1 7/8 15 (12)
1		 13 (4)
5/8-11		 3 1/2 11/16 10 5/8 2
1 1/2 180915-3 (4)
3/4-10		 4 1/2 1 2 7/8
2 180920-3 (8)
5/8-11		 5 3/4 3 5/8
3 180930-3 2 (8)
3/4-10		 6 5/8 5
4 180940-3 7 7/8 6 3/16
6 180960-3 1 1/2 (12)
7/8-9		 (12)
3/4-10		 10 5/8 13/16 8 1/2


Material SG Ultimate Tensile Strength Ultimate Elongation % Continuous temperature range Notes
PTFE 2.13 to 2.19 24.5 250-350 -30° to +200° Almost universal chemical resistance
PFA 2.12 to 2.17 28.5 300 -30° to +200° Almost universal chemical resistance
PVDF 1.75 to 1.78 40 50 0° to +140° Excellent chemical resistance
PP 0.92 26 17 (at yield) -20° to +95° Good chemical resistance
